Programmable Hole-Making Offers More Than Drilling

Manual drilling requires the operator to adjust feed pressure, spindle speed, and coolant flow. Minor variations-chuck wobble, inconsistent pecking rhythm, or inadequate cutting edges-lead to off-center, tapering bore holes or exit burrs that need polishing.
CNC drilling eliminates these factors. Spindle RPM, feed rate in mm/r, peck depth, dwell length, and retract height are all G-coded and same for every hole in every part. It achieves hole position accuracy of ±0.01 mm, diameter consistency within H7 tolerance grades, and surface polish levels below Ra 1.6 µm inside the bore, which human approaches cannot guarantee across production volumes.
That uniformity gives engineers and procurement teams consistent assembly fit, lower rejection rates, and less hole feature post-process scrutiny. The real-world value of CNC drilling services. Not simply technology, but downstream variability reduction.

CNC Drilling in Multi-Process Manufacturing

Production parts rarely have drilling alone. A bracket may need drilled mounting holes, machined edges, and tapped threads on one piece. Our drilling is part of a CNC machining procedure.
On our 3-axis, 4-axis, and 5-axis CNC machining centres, we programme drilling, milling, and tapping sequences in one setup to eliminate cumulative positioning mistakes when parts travel between drilling stations. Pump housings, manifold blocks, and robotic end-effector mounts require hole patterns to match machined datum surfaces.
Face milling creates reference surfaces, spot drilling creates pilot divots to guide tooling, CNC drilling executes the hole pattern to programmed depths and diameters, and tapping or reaming finish the bore to final specifications. Our single-setup technique distinguishes us from shops that drill afterwards.

We have hole geometry capabilities in our CNC drilling services

Not all holes are created equal. Some component designs require separate drilling techniques and we are equipped to undertake all:

Through-Holes with Exact Position Tolerance

Accurate placement is critical when a fastener must go through stacked plates or a fluid port must align with a mating channel . We keep the centre deviations of the holes on multi-axis CNC machining centres within ±0.01 mm, employing robust tool holders and dwell cycles to prevent drill wander on entrance.

Blind holes for depth control

Precision machining is needed for aluminium housings and stainless steel brackets with threaded blind holes, as a too shallow depth may cause fastener bottoming and a too deep depth will diminish wall thickness. Our tool-length probes and Z-axis stops are toleranced to ±0.02 mm in depth with flat-bottomed versions available for special applications.

Deep Drilling and High Aspect Ratios

Oil galleries, cooling channels and structural lightening holes are generally 10:1 depth/diameter ratios. Carbide gun drills and high pressure through-tool coolant delivery with controlled retract keep bores straight and prevent chip packing, a typical deep-hole failure mode.

Micro-Drilling < 1 mm

There is an increasing demand for microfluidic manifolds, fuel injector nozzles and medical device components to have holes measured in fractions of a millimetre. Aluminium Stainless steel Engineering plastics Accurate CNC drilling We drill small holes down to 0.3 mm with high speed spindles (up to 30,000 RPM) and micro-carbide tools.

Material Specific Drilling Performance

Aluminium 6061 and 7075 are the most common alloys for CNC machined parts which mill easily at high spindle speeds (8,000–15,000 RPM) and aggressive feed rates yielding clean holes with few burrs providing coolant delivery is adequate. 7075-T6 aerospace & robotics structural components. Maintain bore finish with deep-hole runs. Prevent chip welding on cutting edges with Peck cycles.

Stainless steel grades 303, 304 and 316 - Work hardening at the cutting interface means lower spindle speeds (800-2,000 RPM), higher feed force and continuous coolant flow is needed to reduce localised heating before the drill point. We employ rigors tool holding, thermally robust carbide drills with TiAlN coatings, and dwell cycles to clear chips before they pack in the flutes.

Titanium Grade 5 (Ti-6Al-4V), which is used in medical implants and high-performance sports equipment, needs even slower spindle speeds below 600 RPM, high-pressure through-tool coolant (minimum 70 bar) and sharp cutting edges to reduce work hardening. Over 16+ years of production our technical team has perfected material specific drilling processes during DFM on every project.

Effective Guidelines for CNC Drilling Design

Better Drilling Results Start Before You Turn the Machine On Based on our DFM experience here are realistic design guidelines for improvement of hole quality, reduction of cost and minimisation of lead time:

To keep tooling consistent the depth of the through-hole should be kept below 5x diameter. Peck drilling will get you to 10:1 ratios, but gun-drilling tooling and special configurations will push cost and lead time beyond 15:1.

Edge distance required: 1.5× hole diameter from centre of hole to nearest part edge. Drilling below this risks a breakout or distortion of the wall.

Provide smooth, perpendicular drill entrance surfaces wherever possible. Drilling on slanted or curved surfaces leads to increased tool deflection and placement inaccuracy.

Are breakout burrs OK? Or does the exit surface need to be machined smooth after drilling for thru-hole exit? It affects process planning.
Standard twist drills have a conical bottom (118° or 135° tip angle) for blind holes. Programme a secondary end-mill operation to produce a flat-bottom hole.

To get a tapped hole , you describe the size of the tap drill you need in your design or 3D model . For metric threads the standard formulas apply (e.g. for M6 × 1.0 a Ø5.0 mm pilot hole is required). In the DFM evaluation, the engineering team examines all the tap drill dimensions.

"With your design with these considerations, our engineering team can quote faster and have higher first-passes."

Why Hole Quality Is the Difference Between a Part and a Problem

- Every hole you drill, is a promise. It claims the fastener will seat, the fluid will flow freely, the press-fit pin will hold under strain and the assembly will come together the same way every time. This dedication is carried through on every part in the order, when drilling are performed with programmed control, strict toolholding and layered quality verification.
- Key-CNC has been providing precision-drilled components to over 1,000 customers in robotics, medical devices, sports equipment and industrial automation since 2008. Our ISO 9001:2015 certified Shenzhen facility employs state-of-the-art multi-axis CNC machining centres with the tooling, fixturing and metrology required to produce hole features to your specifications, from prototype quantities to full production runs.
Request an estimate for your next CNC drilling project and our engineering team will reply with a DFM assessment and pricing within one business day.
